SKU: 18Base
8’x18′ Trailer Base
Key Specifications
Length:
Gas:
Interior:
Floor:
Hood:
Fire:
Water:
Power:
Equipment and Features
NSF Certified
8+ Years Exp.
Built in USA
Description
About This Trailer
8’x18’ Enclosed Kitchen Trailer (20.5’ bumper to bumper)
VENTILATION
- 14’x14’ MAKE-UP AIR VENTILATION
- 15,000 BTU ROOF MOUNTED AIR CONDITIONER
PLUMBING
- NSF APPROVED 3 COMPARMENT SINK WITH 15”X15”X12” BOWL AND 2 DRAIN BOARDS
- NSF APPROVED 14” HAND WASHING SINK WITH 10”X12”X5” BOWL
- 37 GALLON FRESH WATER TANK
- 93 GALLON GREY WATER TANK
- NSF APPROVED, ON-DEMAND WATER PUMP
- 10 GALLON HOT WATER HEATER
- POTABLE WATER INLET WITH A BACK FLOW PREVENTION
GAS
- (2) LOCKABLE PROPANE TANK CAGES, ENCLOSED IN ALL ALUMINUM FRAME
- 400,000 BTU REGULATOR WITH AUTO CHANGEOVER
- 3/4” PROPANE SUPPLY LINE WITH GAS SHUT OFF VALVES
- (2) 100 LB PROPANE CYLINDERS
ELECTRICAL
- 125 AMP, 24 CIRCUIT BREAKER PANEL
- 50 AMP/240 V SERVICE LED
- T8 LIGHTS
- GFCI CONTROLLED OUTLETS
- ALL ELECTRICAL OUTLETS ARE ENCLOSED IN THE WALL TO KEEP YOUR WORK AREA SMOOTH AND CLEAN
- LED OUTDOOR LIGHTS
SAFETY
- ABC FIRE EXTINGUISHER FOR YOUR TRAILER
- SAFETY CHAINS
- ELECTRIC BRAKES ON ALL 4 WHEELS
- BREAKAWAY KIT (STOPPS THE TRAILER IN CASE OF A VEHICLE DISCONNECT)
- FIRST AID KIT
STORAGE
- NSF APPROVED, 18” STAINLESS STEEL STORAGE SHELVES
- LOCKABLE STAINLESS STEEL CABINETS
- STAINLESS STEEL WORK SURFACES
DOORS AND WINDOWS
- 36”X72” MAIN ENTRANCE DOOR
- WINDOW(S) WITH PLEXIGLASS AND SCREENS FOR ADDITIONAL VENTILATION AND EASIER COMMUNICATION
STRUCTURAL
- HARDWOOD FLOOR 1 1/8” WITH 12” CROSS MEMBERS CAPABLE OF WITHHOLDING 8200 LB PER 4”X4” CONCENTRATED LOAD
- 5200 LB DEXTER AXLES WITH ELECTRIC BRAKES
- SOLID ALUMINUM ROOF .030 WITH A SLIGHT BOW TO INCREASE DURABILITY AND TO AVOID COLLECTING WATER
- .040 ALUMINUM SKIN HELD VIA RIVETS, A BOND FOR LIFE
- R13 INSULATION
- 5/8 PLYWOOD BACKING
OTHER
- LED MARKER, BRAKE AND LICENSE PLATE LIGHTS
- STEP AND SAFETY HANDLE TO ENTER THE TRAILER
- ALUMINUM THREAD PLATE FLOORING
- STAINLESS STEEL WALLS
- FRP CEILING
Construction & Materials
Premium materials built to last
Flooring
Diamond-plate aluminum with
seamless welded base cove
Walls
Int: Polished stainless steel
Ext: 18-gauge riveted aluminum
Frame
All-Aluminum
Insulation
R-7 Rated
Floor Plan & Interior Layout
Optimized workspace design for maximum efficiency and compliance
Workspace Zones
01
Prep Area
Dedicated space for food preparation with stainless steel work surfaces
02
Cooking Line
Main cooking zone with equipment-ready connections
03
Hood Zone
Commercial exhaust system with fire suppression
04
Generator Platform
External mounting for generator or shore power connection
Advanced Engineering & Systems
Comprehensive infrastructure designed for high-performance systems and full compliance
Ventilation
Professional-grade ventilation systems designed to meet all health department requirements and keep your kitchen comfortable.
9ft Type 1 Exhaust Hood with Baffle Filters
Roof-Mounted Upblast Exhaust Fan (1500 CFM)
Make-Up Air System with Intake Vents
Fire Suppression System (ANSUL R-102)
Grease Containment System
Plumbing
Complete NSF-certified plumbing system with fresh and waste water management.
3-Compartment Stainless Steel Sink
Hand Wash Sink with Foot Pedal
50 Gallon Fresh Water Tank
50 Gallon Waste Water Tank
On-Demand Water Heater (6 GPM)
Water Pump with Pressure Regulator
Gas
Safe and efficient gas system installation with all required safety features.
Dual 100lb Propane Tank Setup
Gas Manifold Distribution System
Emergency Gas Shutoff Valve
Gas Leak Detection System
Flexible Gas Connectors for All Equipment
Electrical
Heavy-duty electrical system designed for commercial kitchen demands.
100 Amp Main Electrical Panel
50 Amp Shore Power Connection
LED Interior Lighting Package
Exterior LED Lighting
GFCI Protected Outlets Throughout
Dedicated Circuits for Major Equipment
Safety
Comprehensive safety systems meeting all local and state requirements.
Fire Extinguisher (K-Class)
First Aid Kit
Emergency Exit with Push Bar
Non-Slip Diamond Plate Flooring
Carbon Monoxide Detector
Smoke Detector with Alarm
Storage
Maximize your workspace with smart storage solutions.
Overhead Stainless Steel Shelving
Under-Counter Storage Cabinets
Dry Storage Compartment
Utensil Hanging Rails
Spice Rack System
Doors & Windows
Quality doors and windows for ventilation, service, and safety.
48" x 36" Concession Serving Window
Fold-Down Exterior Serving Counter
32" Entry Door with Deadbolt
Emergency Exit Door with Panic Bar
Window Screens Included
Structural
Built to last with premium materials and expert craftsmanship.
All-Aluminum Frame Construction
Insulated Walls (R-7 Rating)
Stainless Steel Interior Walls
One-Piece Rubber Roof Membrane
Tandem Axle with Electric Brakes
Stabilizer Jacks (4 Corners)
Other Components
Additional features that make your trailer complete.
Full Exterior Vinyl Wrap
Retractable Awning (12ft)
External Generator Hookup
Bluetooth Sound System
Security Camera System Ready
Menu Board Mounting Area
Standards & Compliance
Built to meet industry standards and local requirements
NSF Compliant
All food contact surfaces and plumbing components
UL / CSA Listed
Electrical components and equipment
Health Department Ready
Built to meet local health
department requirements
Final Approval
Subject to local Authority Having Jurisdiction (AHJ)
Flexible Financing Options
Start your food business with affordable monthly payments.
Get pre-approved quickly with terms that fit your cash flow.
Get pre-approved quickly with terms that fit your cash flow.
Terms from 36 to 60 months
Rates starting at 14,5%
Loans up to $200,000
Quick Payment Estimate
Trailer Price
Contact for Price
Term Options
36-60 months
Pre-Approval
In Minutes
Customization Options
Every aspect of this trailer can be tailored to your specific needs. Work with our team to create the perfect mobile kitchen for your business.
Trailer length (16ft to 30ft)
Interior layout configuration
Equipment selection and placement
Gas type (Natural Gas or LP)
Electrical setup and capacity
Exterior finish and wrapping
Build Your Custom Food Trailer
Ready to start your mobile food business? Get a custom quote for your
perfect trailer configuration.
5/5 Rating
8+ Years
NSF Certified
Frequently Asked Questions
Got questions? Here are the answers our customers ask most.
Can I build out this trailer base however I want?
That's exactly what it's for. The 8x18 trailer base, 18Base, is a blank foundation – pick the door and window placement, the equipment package, and the finishes, and we'll build the unit up around your menu. Lay it out in our online 3D builder, or call and we'll spec the whole thing with you.
Can the base be finished to pass a health inspection?
Yes. Once it's built out, the interior is clad in 304 stainless steel and run through NSF and California State Certification, so the finished unit clears the health department. Share your county or state rules before we start on the 8x18 trailer and we'll build to them.
What can the 8x18 base support?
Plenty. At eight by eighteen feet, the base carries a full commercial cook line – griddles, fryers, refrigeration, and a hood – with room to work behind the service window. The 8x18 trailer is rated for the loaded weight of a working kitchen, so spec the gear you need and we'll confirm the axles and tongue for it.
How long until a 18Base base is ready?
A bare base moves fast; a full build on top takes longer, and the calendar shifts with our current workload. The closer your spec stays to standard, the sooner it rolls out. Ask for a quote and we'll lock in a build date for your 8x18 trailer.
Will you deliver the base out of state?
We do, anywhere in the country. Whether you want the bare base or a finished unit, we haul it from California to your location. Drop the delivery point into your quote request and we'll roll the freight into the price.
Is the base built to code?
It's fabricated stateside to commercial-kitchen standards, with a welded frame engineered for the road. Built out, the 8x18 trailer earns NSF and California State Certification, plus the certified propane, electrical, and fire-suppression systems that let it run legally as a mobile kitchen.
What warranty comes with the base?
The base ships under a manufacturer warranty on the welded frame and running gear, and any commercial equipment you add carries its own maker's coverage. Terms run differently from part to part. Get in touch and we'll detail the full 18Base protection.
Can the base be financed?
Yes. Whether you buy the base alone or a finished build, we connect you with lenders who specialize in mobile-food ventures, so it needn't be settled in one payment. Look for competitive rates, flexible terms, and one-on-one support from your first unit to a fleet.
What does the 8x18 base cost?
On its own, the 8x18 trailer base is priced as a foundation; the figure climbs as you add equipment, finishes, and custom work. Because every unit is built to order, the surest way to an exact number is a quote or a build in our 3D configurator. Keep towing in mind – loaded out, it weighs well past the bare base, so confirm your tow vehicle is rated for it.
